1000 VC 100TDC Hyd
Köp nu och få det mellan 21.03.26 och 23.03.26
Leveransdatumsintervallet ger dig en indikation på hur lång tid det tar att få varan. Det är baserat på orderhanteringstid, leveranssätt och produkttillgänglighet.
The stainless steel fluted capstan VC Series is designed for simple, low cost anchor recovery on smaller boats and rope hauling on larger vessels.
| Tillverkare | Vetus |
|---|---|
| E (inches) | 10 3/4 |
| Volt DC | No Data |
| Net weight, electric (kg) | No Data |
| Hydraulic pressure (psi) | 1450 |
| Hydraulic flow (gallons/minute) | 5,3 |
| Net weight, hydraulic (lbs) | 24 |
| Hydraulic pressure (bar) | 100 |
| Hydraulic flow (litres/minute) | 20 |
| Net weight, hydraulic (kg) | 11 |
| G (standard deck clearance) (inches) | 4 |
| G (extra deck clearance) (inches) | 6 |
| Max däcktjocklek (mm) | 100 |
| G (extra deck clearance) (mm) | 150 |
| D (standard deck clearance) (inches) | 9 15/16 |
| Line speed (normal working) (m) | 20 m/min |
| Static hold (kg) | No Data |
| Max. dragförmåga (kg) | 700 |
| B (inches) | 4 5/6 |
| F (inches) | 6 5/16 |
| B (mm) | 122,5 |
| Key (E (mm)) | 272 |
| F (mm) | 160 |
| A (inches) | 3 1/8 |
| A (mm) | 80 |
| Motor (W) | No Data |
| Maximum pull/lift (lbs) | 1540 |
| Static hold (lbs) | No Data |
| Line speed (normal working) (feet) | 65 ft/min |
| Net weight, electric (lbs) | No Data |
| D (standard deck clearance) (mm) | 252 |
